| Category | Details |
|---|---|
| General | |
| Brand | MSI |
| Model | PRO X870-P (Wi-Fi 7) |
| Color | Black |
| Form Factor | ATX |
| Power Consumption | Approx. 70W |
| Warranty | 1 Years |
| CPU | |
| Chipset Brand | AMD |
| Chipset | AMD X870 |
| Socket | AM5 |
| Supported CPU | AMD Ryzen 7000 / 8000 / 9000 Series Desktop Processors |
| Built-in Processor | No |
| Memory | |
| Memory Type | DDR5 |
| Supported Speeds | Up to 8200+ MHz (OC), JEDEC: 5600/5400/5200/5000/4800 MHz |
| Max Capacity | 256 GB |
| Memory Slots | 4 x DIMM |
| Channel Configuration | Dual-Channel |
| Optane Support | No |
| Storage | |
| Interface | SATA 6Gb/s |
| SATA Ports | 4 |
| M.2/SSD Expansion | 3 × M.2 Slots |
| M.2 Slot Details | – M.2_1 (CPU): PCIe 5.0 x4 (2280/2260) – M.2_2 (Chipset): PCIe 4.0 x4 (22110/2280) – M.2_3 (Chipset): PCIe 4.0 x2 (2280/2260) |
| RAID Support | RAID 0, 1 |
| Graphics | |
| Graphics Support | Integrated (via CPU) |
| Multi-GPU | Not Supported |
| PCIe Slots | 4 × PCIe x16: – PCI_E1: Gen 5.0 x16 (CPU) – PCI_E2: Gen 3.0 x1 – PCI_E3: Gen 3.0 x1 – PCI_E4: Gen 4.0 x4 |
| Audio & Video | |
| Audio Chipset | Realtek ALC897 |
| Audio Channels | 7.1 |
| HDMI Ports | 1 |
| VGA / DVI / DisplayPort | No |
| Networking | |
| LAN | Realtek 8126VB 5G LAN |
| LAN Speeds | 10/100/1000 Mbps |
| Wi-Fi | Wi-Fi 7 (802.11 a/b/g/n/ac/ax/be) |
| Bluetooth | Bluetooth 5.4 |
| USB Ports | |
| USB 2.0 | 4 × Type-A |
| USB 3.2 Gen 1 (5 Gbps) | 2 × Type-A |
| USB 3.2 Gen 2 (10 Gbps) | 2 × Type-A |
| USB 3.2 Gen 2×2 (20 Gbps) | 1 × Type-C |
| USB4 (40 Gbps) | 1 × Type-C |
| Thunderbolt | 2 × Thunderbolt5 card connectors (internal, JTBT5) |
| Internal Connectors | |
| CPU Power Connectors | 2 × CPU_PWR, 1 × PCIe_PWR (8-pin), 1 × ATX_PWR |
| Fan Headers | 1 × CPU Fan, 1 × Pump/Combo Fan, 6 × System Fan |
| RGB Headers | 3 × Addressable Gen2 (JARGB_V2), 1 × RGB (JRGB) |
| Front Panel | 2 × JFP, 1 × JAUD (Audio), 1 × JCI (Chassis Intrusion), 1 × JDASH (Tuning Controller) |
| TPM Support | 1 × TPM Header (Supports TPM 2.0) |
| Debug Features | 4 × EZ Debug LEDs |
| Special Features | |
| EZ PCIe Clip II | Tool-less GPU removal |
| DDR5 & Memory Boost | Enhanced DDR5 performance with MSI Memory Boost |
| Lightning USB 40G | Built-in USB4 offering up to 40 Gbps transfer speeds |
| Lightning Gen 5 | PCIe 5.0 support with up to 128 GB/s bandwidth |
| M.2 Shield Frozr | Thermal protection for M.2 drives |
| Frozr AI Cooling | Automatic fan tuning based on CPU/GPU temperatures |
| Extended Heatsink Design | Large heatsinks for stable VRM cooling |
| Pre-installed I/O Shield | For easier installation and EMI protection |
| OS Compatibility | Windows 11 |
-15%
MSI PRO X870-P WIFI AMD MOTHERBOARD | 911-7E47-010
Original price was: 110.000 KD.94.000 KDCurrent price is: 94.000 KD.
-
Next-Gen CPU Support – Compatible with AMD Ryzen 7000, 8000, and 9000 Series processors on the AM5 socket with the powerful X870 chipset.
-
Blazing-Fast Connectivity – Equipped with Wi-Fi 7, 5G LAN, and USB4 (40Gbps) for ultra-fast networking and data transfer.
-
High-Speed DDR5 Memory – Supports up to 256GB of DDR5 RAM with speeds exceeding 8200MHz (OC) for maximum performance.
-
Advanced Storage Options – Includes 3× M.2 slots (PCIe 5.0 & 4.0) with M.2 Shield Frozr and 4× SATA ports for flexible storage setups.
-
Durable & Cool Design – Features extended heatsinks, EZ PCIe Clip II, RGB headers, and Frozr AI Cooling for stable and user-friendly operation.
