NZXT H5 Flow (2024) Compact Mid-Tower ATX Case – White
Specification | Details |
---|---|
Model No | NZXT H5 Flow (2024) |
Part No | CC-H52FW-01 |
Color | White |
Motherboard Support | ATX, E-ATX, Micro-ATX, Mini-ITX |
External Drive Bays | No |
Internal Drive Bays | 2x 2.5″, 1x 3.5″ |
Expansion Slots | 7x Full Height |
Max GPU Length | 410 mm / 16.1″ |
CPU Cooler Height | 175 mm / 6.9″ |
Supported PSU Size | ATX |
Max PSU Length | 200 mm / 7.9″ |
PSU Mounting Location | Bottom |
Fan Mounting – Front | 3x 120 mm or 2x 140 mm |
Fan Mounting – Top | 2x 120/140 mm |
Fan Mounting – Bottom | 2x 120 mm |
Fan Mounting – Rear | 1x 120 mm |
Fans Included | Front: 1x 120 mm Non-LED, Rear: 1x 120 mm Non-LED |
Fan Speed | 1350 rpm |
Max Radiator Size – Front | 360 mm |
Max Radiator Size – Top | 240 mm |
Noise Level | 24.1 dBA |
Fan Controller Included | No |
Filter Locations | Bottom, Front, Top |
I/O Ports | 1x USB-A (3.2 Gen 1), 1x USB-C (3.2 Gen 1), 1x 3.5mm Audio I/O |
Windowed Panel | Yes |
Material | Steel, Tempered Glass |
Tool-Less Design | Thumbscrews |
Cable Management Space | 28.7 mm / 1.1″ |
Dimensions (W x H x D) | 430 x 465 x 225 mm / 16.9 x 18.3 x 8.9″ |
Weight | 7.13 kg / 15.72 lb |
Package Weight | 20 lb |
Box Dimensions (L x W x H) | 22 x 20.75 x 12.25″ |
Warranty | 1 Year (As Per Manufacturer) |
