GIGABYTE X870E AORUS MASTER X3D ICE Motherboard Specifications:
| CATEGORY | SPECIFICATION |
|---|---|
| Model | GIGABYTE X870E AORUS MASTER X3D ICE – White |
| Part No | X870E A MASTER X ICE |
| CPU Socket | AMD Socket AM5 – Supports Ryzen™ 7000 / 8000 / 9000 Series Processors |
| Chipset | AMD X870E |
| Memory Support | 4 × DDR5 DIMM, up to 256GB, Dual Channel, AMD EXPO™ / XMP Support, DDR5 4800–9000(O.C) MT/s |
| Integrated Graphics | AMD Radeon™ Graphics Support (Depends on CPU) |
| PCIe Slots | 1 × PCIe x16 (CPU) – PCIe 5.0 / 4.0 support depending on CPU 1 × PCIe x16 (CPU) – PCIe 4.0 / 5.0 x8 1 × PCIe x16 (Chipset) – PCIe 4.0 x4 |
| Storage Interfaces | 5 × M.2 Slots (PCIe 5.0 / 4.0 support per CPU/Chipset) 2 × SATA 6Gb/s |
| USB Ports | 2 × USB4® Type-C (Front/Back) Multiple USB 3.2 Gen2/Gen1 & USB2.0 ports |
| LAN | 1 × Realtek 5GbE LAN, 1 × Realtek 10GbE LAN |
| Wireless | MediaTek Wi-Fi 7 MT7927, Bluetooth 5.4 |
| Audio | Realtek ALC1220 Codec, ESS ES9118 DAC, DTS:X Ultra Support, 2/4/5.1-channel |
| VRM & Power | Digital Twin VRM, 18 × VCORE Phases SPS 110A, 2 × SOC Phases SPS 110A, 2 × MISC Phases Dr.MOS 60A |
| Cooling | Full-metal heatsinks, Premium VRM Armor, Direct-touch Heatpipe, M.2 Thermal Guard XL |
| RGB & Accessories | Multiple Addressable RGB & Standard RGB headers, Lian Li / Strimmer ready |
| BIOS & Software | Licensed AMI UEFI BIOS, Q-Flash, Q-Flash Plus, Smart Backup, GIGABYTE Control Center Support |
| Form Factor | ATX (30.5 × 24.4 cm) |
| Operating System | Windows 11 64-bit Support |
| Warranty | 1 Year (As per Manufacturer Policy) |
⚙️ Features & Connectivity Highlights
| ITEM | DETAILS |
|---|---|
| X3D Turbo Mode 2.0 | AI-powered real-time optimization boosting Ryzen™ X3D performance up to 25% with one-click acceleration |
| Memory Boost | Advanced DDR5 performance and compatibility enhancements |
| PCB Design | 8-layer server-grade PCB, 2× copper, back drilling, low dissipation factor for high-speed signal integrity |
| Connectivity | Front QC-USB 65W, Dual 40Gbps USB4®, Dual 10G + 5G LAN, Wi-Fi 7 |
| Ultra Durable™ | Premium reliability and longevity with reinforced VRM, heatsinks, and advanced thermal design |
